Beskrivning
Keyboard: | 88-note, fully-weighted hammer-action with velocity sensitive keys (Fatar TP/110) |
Display: | 1024 x 600 pixel, high resolution 7″ color LCD touch screen |
Enclosure Material: | Steel + Aluminum |
Enclosure Color: | Black |
Polyphony: | 256 |
Multitimbral: | 16 parts (one per MIDI channel) |
Architecture: | A.T.S.T. – Authentic Timbre Synthesis Technology Featuring fixed PCM subtractive with variable filter and 2x oversampling state variable 96 kHz filter |
Factory Samples: | 2 GB |
Factory Programs: | 301 |
Factory Multis: | 512 |
User Multis: | 128 |
Multi Zones: | 16 |
Favorites | 64 |
General MIDI: | GM2 |
Piano String Resonance: | Yes |
Piano Damper Resonance: | Yes |
Master EQ: | 4-Band |
Aux FX Busses: | 2 |
Insert Effects: | Reverb: 6 Algorithms Modulation: BPM-Sync’d Delay, Chorus/Flanger, Rotary Speaker, Vibrato, Tremolo, Auto Wah-Wah Dynamic: Compression, Noise Gate Distortion: Dist/Ovd/Tube/Fuzz, Bit Crusher EQ: 4-Band, Hi/Low Shelf, Peak/Notch, Hi/Low Pass |
Vocal Pitch Correction: | Yes / Automatic |
Vocal Harmony Generation: | 4-Part |
Controllers: | 1 Pitch/Mod Joystick 8 Knobs 8 Buttons 2 Transpose switches 2 Switch pedal inputs; supports a single half-damper pedal (1 switch/sustain pedal is included; half-damper pedals sold separately) 1 Continuous Control Pedal Input (pedal sold separately) |
Arpeggiator: | 8 – Hybrid-Arpeggiators |
System Sample Rate: | 48kHz (max 192 kHz) |
System Bit Rate: | 48 bit (fixed point) |
Analog Inputs: | 2 XLR-1/4″ balanced combi |
Analog Outputs: | Main: 2, 1/4″ TRS balanced Monitor: 2, 1/4″ TRS balanced |
Headphone: | 1 back panel 1/4″ headphone output |
MIDI: | In, Out |
USB MIDI: | 1 Type B port |
USB Audio Interface: | 2-In/2-Out; 24-bit/48kHz |
Software Editor: | External Macro Synthesis Editor (coming soon) |
OS Updates: | via USB (Engine firmware), via SD card (GUI firmware) |
Accessories: | Included: power cable, switch pedal, USB cable, 1/4″ TRS cable |
Height: | 4.7″ (12 cm) |
Depth: | 14.6″ (37 cm) |
Length: | 52″ (132 cm) |
Weight: | 36 lb (16.3 kg) |
Power: | External 15VDC 2.5A Power Supply |
