Beskrivning
Klaviatur TP-100 LR: 88 – Keys Hammer action – Triple contact
Ljudmotor Advanced T2L: Sampling and Modelling Technology
Sampling XXL wave size, up to 15 seconds on lower piano notes
Samplingsformat 24 bit linear – 48 KHz (Internal processing and DSP at 32 bit floating)
DA-omvanling: 24 bit linear – 48 KHz, Dynamic Range, S/N:106dB
Max Polyfoni Obegränsad med 320 Oscillator
Orgel-modellering TW1 (Tone Wheel), TW2, FARF (Farfisa), VX (Vox), PIPE + User1, User2 downloadable from website
Ljud Över 100 Organ Preset + 180 Sounds + User downloadable from website
Tone Wheel 9 virtual draw faders on LCD for Tone Wheels
Memory Internal 81 Unlimited loadable from USB Memory
Sampleminne 3.2 GB full konfigurerbart med Dexibells eget format och Sound Font Format
Antal lager 4, MAIN, LOWER, COUPLED, PEDAL + 4 MIDI zones
Anslagskänlighet 7 Typer + Fixed
Reverb 24 Typer
Effekter Rotary, Overdrive, Vibrato/Chorus for Organ + 12 Independent DSP x 17 types (3 x Main, 3 x Coupled, 3 x Lower, 3 x Pedal) using “seamless changes” technology at effect recall
Master Equalizer 3-band Digital Equalizer
Chord Enhancer YES
Kontroller FX Encoder x 6, Data Entry/Song Level Encoder x 1
Master Volume Knob, Wheel 1 & Wheel 2
Button Assign 2
Spelar upp .wav, .aiff, .mp3, in all format, frequency and bit rate
Spelar in .wav (48 kHz, 32-bit floating) på USB-minne
Master Tuning 415,4 Hz to 466,1 Hz (adjustable increments of 0,1 Hz)+ 2 Preset (440 Hz, 442 Hz)
Temperament 9 Types
User Temperament YES: 3 User
Rhytmer X MURE APP for i-Phone and i-Pad (FREE) with multitracks audio patterns
Anslutningar
OUTPUT: MAIN Balanced: XLR (LR) MAIN / SUB Unbalanced OUTPUT jacks (L/MONO, R) 1/4-inch phone type
FOOT 1: Progressive Damper Action Pedal with sympathetic resonance simulation
FOOT 2: Function assignable
FOOT 3: Expression Pedal / Function assignable
FOOT 4: Morphing Pedal / Function assignable
MIDI: IN, OUT, THRU
USB: TO HOST (MIDI & DIGITAL AUDIO IN/OUT), TO DEVICE (MEMORY & MIDI)
AUX IN: 1 jack (stereo mini-jack)
Bluetooth Streaming Audio Input, MIDI BLE 4.2
Display Graphic LCD 128 x 64 dots Organic LED, high contrast type
Högtalare 2 Full range x 8.9 cm (3,5 inches)
Rated Power Output 35 W x 2 max @ THD+N < 0.1%
Volume Level SPL 108.1 dB max
Strömförbrukning
STAND BY: < 0,2 W
MAXIMUM: 18 W
“ErP” LEVEL VI for Echo efficiency on stand-by consumption
Mått
Bredd 1270 mm
Djup 375 mm
Höjd 126 mm
Vikt 15,4 Kg
